DQ Heating Cove 550mm High Horizontal Radiator

DQ Heating Cove 550mm High Horizontal Radiator

Name: DQ Heating Cove 550mm High Horizontal Radiator
Brand: DQ Heating
SKU: COVE550/7-W
Price: 111.47 GBP
Availability: InStock

More Finishes And Sizes Available

No Rating

Write a Review

Rate This:

MFC Code : COVE550/7-W

Product Code : 31213

Shipping: FREE

£111.47

RRP : £162.00

SELECT Variation Step 1

Single Column
£111.47
Double Column
£156.06

SELECT FINISH Step 2

SELECT Width Step 3

413mm Width
590mm Width
826mm Width
1003mm Width
1180mm Width

qty :

Read More About the Product

Towel Hanging Rail Chrome

Towel hanging rail from DQ Heating. Please Note : Image shown is for illustration purpose only.

None
OP-52384 - Cove Chrome Towel Hanging Rail + £50.00

DQ Grip Peg

Handy for the Kitchen or Bathroom where that extra towel or tea towel hangs on the bar and not the radiator. Choice of either Chrome or White finish. Image shown is for illustration prupose only.

None
OP-43742 - Grip Peg - Chrome + £20.00
OP-43741 - Grip Peg - White + £20.00

VIP Hook Option

Modern style VIP hook to add beauty to your radiator. Image is for illustration purpose only.

None
OP-43740 - VIP Hook - Chrome + £20.00
OP-43739 - VIP Hook - White + £20.00

About This Product

Available in 2 finishes And variations
Height : 550mm (55cm)
Manufactured from mild steel
Test pressure : 8 Bar
Maximum operation pressure : 6 Bar
Maximum working temperature : 95c
1/2inch flow and return connection
Image shown is for illustration purpose only
Refer technical diagram for complete technical dimensions
Valves shown in the image are not included
Guarantee : 5 Years.

Technical Info

Download Installation Instrutions PDF

PRODUCT VARIATIONS INFO & MFC CODE

Details Of Cove Single Horizontal Radiator

Product Code	Finish	Width	Height	Watts	BTU	Weight	Wall To Pipe	Wall To Face
COVE550/7-A	Anthracite	413	550	275	938	10	50	90
COVE550/10-A	Anthracite	590	550	390	1331	12	50	90
COVE550/14-A	Anthracite	826	550	550	1877	14	50	90
COVE550/17-A	Anthracite	1003	550	665	2269	16	50	90
COVE550/20-A	Anthracite	1180	550	780	2661	18	50	90
COVE550/7-W	White	413	550	275	938	10	50	90
COVE550/10-W	White	590	550	390	1331	12	50	90
COVE550/14-W	White	826	550	550	1877	14	50	90
COVE550/17-W	White	1003	550	665	2269	16	50	90
COVE550/20-W	White	1180	550	780	2661	18	50	90

Details Of Cove Double Horizontal Radiator

Product Code	Finish	Width	Height	Watts	BTU	Weight	Wall To Pipe	Wall To Face
COVE550/7D-A	Anthracite	413	550	440	1501	17	50	90
COVE550/10D-A	Anthracite	590	550	625	2133	19	50	90
COVE550/14D-A	Anthracite	826	550	880	3003	21	50	90
COVE550/17D-A	Anthracite	1003	550	1065	3634	24	50	90
COVE550/20D-A	Anthracite	1180	550	1250	4265	27	50	90
COVE550/7D-W	White	413	550	440	1501	17	50	90
COVE550/10D-W	White	590	550	625	2133	19	50	90
COVE550/14D-W	White	826	550	880	3003	21	50	90
COVE550/17D-W	White	1003	550	1065	3634	24	50	90
COVE550/20D-W	White	1180	550	1250	4265	27	50	90
