Reina Serena Mild Steel Designer Radiator 500mm Wide

Reina Logo
More Sizes And Finishes Available
Overall Rating: Stars Rating 5 out of 5 customers rated 60%
Rate This:
MFC Code : RND-SRN5050A
Product Code : 9093
Delivery: £34.95
£126.91
RRP : £158.64
SELECT FINISH Step 1

SELECT Height Step 2

SELECT Radiator Type Step 3

SELECT Heating Element Type Step 4

SELECT Essential Accessories Step 5

qty :
Compatible Valves Read More About the Product
Questions Ask Technical Question?
Reviews Write a Review
Check Availability 5 Working Days Apprx

Options & Accessories: You May Require

Chrome Pipe Kit
Accessories

Reina provides an optional Chrome Pipe Kit that you may require for the installation. These kit are highly recommended from the manufacturer. Please note: Image shown is for illustration purpose only.



About This Product

  • Suitable for central, electric and dual fuel heating systems
  • Constructed using mild steel
  • Comes with an Air vent and End plug
  • Brackets for radiator included
  • EN 442 Compliant product
  • The image shown is for illustration purposes only
  • The valves shown in the image are not included
  • Width: 500mm (30cm)
  • Pipe centres: 470mm (27cm)
  • Wall to pipe centres: 65-80mm (6.5-8cm)
  • Distance from wall: 80-95mm (8-9.5cm)
  • For Heating Element Manual Instructions and Details download the PDF from the technical tab
  • Technical drawing available for more technical details
  • Guarantee: 5 years from Reina against manufacturing defects.
  • Please Note:
  • The appropriate wattage of the element (if selected) will be decided by the manufacturer, once the order is placed.
  • Available Optional Products:
  • Choice of different heights: 500mm, 800mm and 1200mm
  • Different finishes available Anthracite and Chrome
  • Available variants: Central heating, Dual Fuel and Electric
  • Different types of heating elements are available
  • Valves
  • Sleeving kit and chrome pipe kit
  • T-Piece - For Dual Fuel Only
  • Liquid Filling For Electric Only.

Information Breakdown

Colour Anthracite
Warranty/Guarantee 5 Years
Width 500
Projection (Depth) 80-95
Compliance/Approvals/Standard EN 442
Orientation V
BTU Output 70°C - 1082
Watts 70°C - 317
Tapping / Pipe Centres 470
Valves Included Sold Separately
Wall to Centre of Inlet 65-80
Brackets Included Yes
Installation Type Wall Mounted
Compatible Valves

Technical Info

Reina Serena Mild Steel Designer Radiator 500mm Wide

Download Heating Element Manual Instructions PDF

Download Details Of Heating Elements PDF


PRODUCT VARIATIONS INFO & MFC CODE
  • Details For Anthracite Steel Designer Radiator
    Width 500mm 800mm 1200m
    Finish Anthracite Anthracite Anthracite
    MFC RND-SRN5050A RND-SRN5080A RND-SRN5120A
    Pipe Centres 470 470 470
    Wall to Pipe centres 65-80 65-80 65-80
    Wall Distance 80-95 80-95 80-95
    Tube Quantity 5 7 10
    Total Gap 4 6 9
    Fuel Type Central/Electric/Duel Central/Electric/Duel Central/Electric/Duel
    Watts - Delta-70 317 507 761
    BTU - Delta-70 1082 1730 2596
    BTU - Delta-60 887 1418 2128
    BTU - Delta-50 698 1116 1675
    BTU - Delta-45 608 972 1458
    BTU - Delta-40 525 840 1260
    BTU - Delta-35 440 703 1055
    BTU - Delta-30 357 571 857
    BTU - Delta-25 139 222 334
  • Details For Chrome Steel Designer Radiator
    Width 500mm 800mm 1200m
    Finish Chrome Chrome Chrome
    MFC RND-SRN5050 RND-SRN5080 RND-SRN5120
    Pipe Centres 470 470 470
    Wall to Pipe centres 65-80 65-80 65-80
    Wall Distance 80-95 80-95 80-95
    Tube Quantity 5 7 10
    Total Gap 4 6 9
    Fuel Type Central/Electric/Duel Central/Electric/Duel Central/Electric/Duel
    Watts - Delta-70 225 357 536
    BTU - Delta-70 767 1218 1828
    BTU - Delta-60 629 998 1498
    BTU - Delta-50 495 786 1179
    BTU - Delta-45 431 684 1027
    BTU - Delta-40 372 591 887
    BTU - Delta-35 312 495 743
    BTU - Delta-30 253 402 603
    BTU - Delta-25 99 157 235
  • Detail For Heating Elements
    Variant MFC
    Standard Heating Element ELM/S
    On/Off Touch Element ELMOOT
    LST Mini Round Thermostatic Element ELMMRNLST
    Mini Round Thermostatic Element ELMMRN
    Touch Thermostatic Heating Element ELMTCH
    LST Weekly Thermostatic Element ELMWKYLST
    Weekly Thermostatic Element ELMWKY
  • Details For Accessories
    Type MFC
    T-Piece - For Dual Fuel Only ACCS/TP
    Liquid Filling For Electric Only A/FILLING1
