Name: Reina Rione White Steel Double Panel Designer Radiator 550mm High
Brand: Reina
SKU: RND-RNE400D
Price: 174.62 GBP
Availability: InStock

About This Product

Available in different widths: 400mm, 600mm, 800mm, 1000mm, 1200mm and 1400mm - [See Option]
Available variants: Central heating, Dual Fuel and Electric - [See Option]
Heating element type: Standard, On/Off Touch, LST Mini Round Thermostatic, Mini Round, Touch Thermostatic, LST Weekly Thermostatic and Weekly Thermostatic - [See Option]
Double panel designer radiator
Material: Steel
Finish: White
Height: 544mm (54.4cm)
Wall to pipe centres: 78mm (7.8cm)
Distance from wall: 107mm (10.7cm)
Tube Quantity: 16
EN 442 compliant product
For BTU and Watts, Please refer to the Product Variations Info and MFC Code section
Suitable for central, electric and dual fuel heating systems
Supplied with Air vent and End plug
Brackets for radiator included
For the Dual Fuel and Electric model, Heating Elements are highly recommended in combination with T-Piece
For Electric models, Optional Liquid Filling is required with the heating element
Download the Heating Element PDF files from the Technical Info section
The valves and chrome pipe shown in the image are not included
Refer technical diagram for complete technical dimensions
Guarantee: Five years from Reina against manufacturing defects.
Available Optional Products:
Valves
Sleeving kit and chrome pipe kit.
Please Note: The appropriate wattage of the element (if selected) will be decided by the manufacturer, once the order is placed.

Information Breakdown

Colour	White
Warranty/Guarantee	5 Years
Width	400
Orientation	Horizontal
BTU Output	70°C - 2110
Watts	70°C - 619
Wall to Centre of Inlet	78
Panel Configuration	Double
Installation Type	Wall Mounted \| Floor Mounted

Compatible Valves

Technical Info

Reina Rione White Steel Double Panel Designer Radiator 550mm High

Download Heating Element Manual Instructions PDF

Download Details Of Heating Elements PDF

PRODUCT VARIATIONS INFO & MFC CODE

Specifications Of 550mm High Radiator

Width	400mm	600mm	800mm	1000mm	1200mm	1400mm
Pipe Centres	355mm	555mm	755mm	955mm	1155m	1355mm
Wall To Pipe Centre	68mm	68mm	68mm	68mm	68mm	68mm
Wall Distance	97mm	97mm	97mm	97mm	97mm	97mm
Tube Quantity	16	16	16	16	16	16
Watts - Delta-70	619	928	1238	1547	1857	2167
BTU - Delta-70	2110	3166	4221	5276	6334	7389
BTU - Delta-60	1730	2595	3460	4325	5192	6057
BTU - Delta-50	1361	2043	2723	3404	4086	4767
BTU - Delta-45	1185	1779	2371	2964	3558	4151
BTU - Delta-40	1024	1537	2049	2561	3075	3587
BTU - Delta-35	858	1287	1716	2145	2575	3004
BTU - Delta-30	696	1045	1393	1741	2090	2439
BTU - Delta-25	271	407	543	678	814	950
MFC	RND-RNE400D	RND-RNE600D	RND-RNE800D	RND-RNE1000D	RND-RNE1200D	RND-RNE1400D

Specifications Of Elements And Accessories

Variants	MFC
Standard Element	ELM/S
On/Off Touch Element	ELMOOT
LST Mini Round Thermostatic Element	ELMMRNLST
Mini Round Thermostatic Element	ELMMRN
Touch Thermostatic Element	ELMTCH
LST Weekly Thermostatic Element	ELMWKYLST
Weekly Thermostatic Element	ELMWKY
T-Piece Connector	ACCS/TP
Liquid Filling - For Electric Only	A/FILLING1
