Name: Ideal Standard Ceratherm S200 Exposed Thermostatic Shelf Shower Mixer
Brand: Ideal Standard
SKU: A7329AA
Price: 278.62 GBP
Availability: InStock

About This Product

Material: Brass
Precitherm® cartridge
Technology: Cool Body
Complies with EN1111
Dimension: 314mm x 125mm x 75mm Width x Depth x Height)
Depth with buttons: 150mm (15cm)
Inlet center: 150mm +/-13mm
Button diameter: 42mm (4.2cm)
Weight: 3.03 kg
Supplied with s-connection wall brackets
The minimum operating water pressure is 0.5 bar
Flow rate: 23 litres per minute at 3 bar pressure system
For complete size details, please refer to the technical drawing
Guarantee: 5 years from the manufacturer against any manufacturing defects
Download the Installation Instruction PDF File From the Technical Info Tab
Specification:
Temperature safety button
Water and saving energy
Shelf for more space for bath products
The exposed model with fixation system without visible nuts
Shelf made of back-painted safety glass – white
IS Thermostatic cartridge new technology
Thermostatic control – via rotary knob
Temperature override feature at 40 °C
Volume control with a rotary knob and Ceramic valve, ±90° operation
Eco stop at half-flow
Easy operation thanks to forward-facing controls
Also, with a G ½” central shower outlet from metal
Check valves for both inlets

Information Breakdown

Colour	Chrome \| Silk Black
Country of Origin	EU
Warranty/Guarantee	5 Years
Theme	Modern
Compliance/Approvals/Standard	EN1111
Water Saving	Yes
Handle Style	Knob
Valve Included	Yes
Inlet Centres	150
Technologies	Cool Body
Temperature Control	Thermostatic
Number of Handles	2
Number of Outlet	1
Orientation	Landscape
Numbered temperature control	Yes
Outlet Connection	G 1/2"
Maximum Operating Pressure (Bar)	3
Overall Width	314
Cartridge Included	Yes
Cartridge Type	Precitherm
Minimum Operating Pressure (Bar)	0.5

Technical Info

Ideal Standard Ceratherm S200 Exposed Thermostatic Shelf Shower Mixer

Download Data Sheet Chrome PDF

Download Data Sheet Silk Black PDF

Download Installation Instruction PDF

Download Flow Rate PDF

Download Declaration Of Conformity PDF

PRODUCT VARIATIONS INFO & MFC CODE

Available Finishes

Finish	MFC
Chrome	A7329AA
Silk Black	A7329XG
