Name: Reina Artena 590mm High Single Panel Stainless Steel Radiator
Brand: Reina
SKU: RNS-AT904P
Price: 218.4 GBP
Availability: InStock

About This Product

Choice of different finishes: Polished and Brushed - [See Option]
Available in different widths: 400mm, 600mm, 800mm, 1000mm and 1200mm - [See Option]
Available variants: Central heating, Dual Fuel and Electric - [See Option]
Choice of heating element available - [See Option]
Material: Stainless steel
Height: 590mm (59cm)
Wall to pipe centres: 65mm (6.5cm)
Wall distance: 103mm (10.3cm)
Tube Quantity: 10
Brackets for radiator included
Supplied with Air vent and End plug
EN 442 Compliant Product
The valves shown in the image are not included
For BTU and Watts, Please Refer to the Chart in the Product Variations Info & MFC Code section
For more information on Elements options download the Elements PDF File from the Technical Info Section
Refer to the technical drawing for more details
Guarantee: Twenty-five-year from Reina against manufacturing defects
Available Optional Product:
Sleeving kit and chrome pipe kit
Compatible Valves
T-Piece - For Dual Fuel Only
Liquid Filling For Electric Only
Please Note:
The appropriate wattage of the element (if selected) will be decided by the manufacturer, once the order is placed.

Information Breakdown

Colour	Polished
Warranty/Guarantee	25 Years
Width	400
Orientation	Horizontal
BTU Output	1719
Watts	504
Tapping / Pipe Centres	360
Valves Included	Sold Separately
Wall to Centre of Inlet	65
Brackets Included	Yes
Panel Configuration	Single
Installation Type	Wall-Mounted

Radiator Valves

Technical Info

Reina Artena 590mm High Single Panel Stainless Steel Radiator

Download Mounting Instruction PDF

PRODUCT VARIATIONS INFO & MFC CODE

Specification For Polished Radiator

Variants	Width - 400mm	Width - 600mm	Width - 800mm	Width - 1000mm	Width - 1200mm
Fuel Type	Central Heating /Electric/Dual Fuel	Central Heating /Electric/Dual Fuel	Central Heating /Electric/Dual Fuel	Central Heating	Central Heating
Finish	Polished	Polished	Polished	Polished	Polished
Height	590mm	590mm	590mm	590mm	590mm
Pipe Centres	360mm	560mm	760mm	960mm	1160mm
Wall To Pipe Centre	65mm	65mm	65mm	65mm	65mm
Wall Distance	103mm	103mm	103mm	103mm	103mm
Tube Quantity	10	10	10	10	10
Watts - Delta-70	504	756	1009	1260	1513
BTU - Delta-70	1719	2579	3439	4298	5158
BTU - Delta-60	1409	2114	2819	3523	4228
BTU - Delta-50	1109	1664	2219	2773	3328
BTU - Delta-45	966	1449	1932	2415	2898
BTU - Delta-40	834	1252	1669	2086	2504
BTU - Delta-35	699	1048	1398	1747	2097
BTU - Delta-30	567	851	1135	1418	1702
BTU - Delta-25	221	331	442	552	663
MFC	RNS-AT904P	RNS-AT906P	RNS-AT908P	RNS-AT910P	RNS-AT912P

Specification For Brushed Radiator

Variants	Width - 400mm	Width - 600mm	Width - 800mm	Width - 1000mm	Width - 1200mm
Fuel Type	Central Heating /Electric/Dual Fuel	Central Heating /Electric/Dual Fuel	Central Heating /Electric/Dual Fuel	Central Heating	Central Heating
Finish	Brushed	Brushed	Brushed	Brushed	Brushed
Height	590mm	590mm	590mm	590mm	590mm
Pipe Centres	360mm	560mm	760mm	960mm	1160mm
Wall To Pipe Centre	65mm	65mm	65mm	65mm	65mm
Wall Distance	103mm	103mm	103mm	103mm	103mm
Tube Quantity	10	10	10	10	10
Watts - Delta-70	504	756	1009	1260	1513
BTU - Delta-70	1719	2579	3439	4298	5158
BTU - Delta-60	1409	2114	2819	3523	4228
BTU - Delta-50	1109	1664	2219	2773	3328
BTU - Delta-45	966	1449	1932	2415	2898
BTU - Delta-40	834	1252	1669	2086	2504
BTU - Delta-35	699	1048	1398	1747	2097
BTU - Delta-30	567	851	1135	1418	1702
BTU - Delta-25	221	331	442	552	663
MFC	RNS-AT904B	RNS-AT906B	RNS-AT908B	RNS-AT910B	RNS-AT912B

Specification For Heating Elements

Variants	MFC
Standard Heating Element	ELM/S
On/Off Touch Element	ELMOOT
LST Mini Round Thermostatic Element	ELMMRNLST
Mini Round Thermostatic Element	ELMMRN
Touch Thermostatic Heating Element	ELMTCH
LST Weekly Thermostatic Element	ELMWKYLST
Weekly Thermostatic Element	ELMWKY

Specification For Accessories

TYPE	MFC
T-Piece - For Dual Fuel Only	ACCS/TP
Liquid Filling For Electric Only	A/FILLING1
