Nuie 500mm Wide Curved Heated Towel Rail

Name: Nuie 500mm Wide Curved Heated Towel Rail
Brand: Nuie
SKU: MTY102
Price: 45.2 GBP
Availability: InStock

Overall Rating:

1 out of 1 customers rated 20%

Rate This:

MFC Code : MTY102

Product Code : 22902

Delivery: £34.95

£45.20

RRP : £113.00

SELECT FINISH Step 1

SELECT Height Step 2

SELECT Summer Heating Elements Step 3

SELECT Radiator Hook Step 4

qty :

Former Known as Premier Curved Heated Towel Rail - MTY102
Choice of different finish: Anthracite and Chrome - [See Option]
Available in different height: 700mm, 1100mm and 1150mm - [See Option]
Material: Steel
Width: 500mm (50cm)
Luxury heated ladder rail
It comes complete with Brackets and fixing screws
Suitable for use with heating elements
All tappings are 1/2 inch BSP
CE Certified
Image shown is for illustration purpose only
Valves and elements are not included
For Details on Towel rail, refer to the chart at the PRODUCT VARIATIONS INFO & MFC CODE tab below
Download Data Sheet and Fitting Instruction PDF File from the Technical Info Section
After installing, when refilling the system, it is recommended that a suitable inhibitor is used
We recommend pipework is not installed until receipt of radiator or heated towel rail
Guarantee: Five years from Nuie against manufacturing defects.
Available Optional Products:
Compatible Valves
Electric Element
Radiator Hook.

Compatible Valves

Download Technical Data Sheet For 500 x 700mm PDF

Download Technical Data Sheet For 500 x 1150mm PDF

Download Technical Data Sheet For 500 x 1100mm PDF

Download Fitting Instruction PDF

Specifications For Curved Towel Rail

Height	Projection	Finish	BTU At 30 Deg.C	BTU At 50 Deg.C	BTU At 60 Deg.C	Watts At 30 Deg.C	Watts At 50 Deg.C	Watts At 60 Deg.C	Pipe Centres	Number Of Tube	Heat Settings	Packaging Volume (L)	MFC
700mm	100mm	Anthracite	560	1051	1331	164	308	386	450mm	13	1	23	MTY102
1150mm	70mm	Anthracite	894	1689	2139	262	495	622	450mm	21	1	37	MTY104
-	-	-	-	-	-	-	-	-	-	-	-	-	-
700mm	90mm	Chrome	710	366	899	208	107	258	450mm	14	1	-	HK385
1100mm	-	Chrome	1126	581	1426	330	170	410	450mm	-	-	-	HK386
